Product Descreiption
1. Basic Specifications
- Applicable Engine：Cummins QSL8.9 / ISL8.9 diesel engine, 8.9L displacement, construction machinery engine
- Material：Reinforced nylon housing, built-in oil separation filter screen
- Net Weight：About 0.7kg / pc
- Structure：2 mounting holes, 1 big crankcase connecting port, 1 small gas outlet pipe, no motor, no electric component, no coil
2. Installation Position
Mounted by bolts on the side of engine cylinder block / crankcase cover, connects directly to engine crankcase inner cavity via main interface; the small outlet nipple links rubber hose to engine intake pipe for closed ventilation。
3. Product Function
- Balance internal pressure of engine crankcase, release blow-by gas leaked from piston ring during engine running to avoid crankcase overpressure & oil seal leakage。
- Separate engine oil mist from blow-by gas via internal filter element, recycle oil back to crankcase, reduce engine oil consumption。
- Purify waste gas, feed cleaned gas into engine intake for secondary combustion, lower exhaust emission, protect engine lubrication system from corrosion by acidic exhaust gas。
